About the label data CSVs

When you export your nutrition label data from Foodworks, the data is exported into two CSVs. This data is organised into two tables which can be used by your label publishing software to create nutrition labels using the Foodworks analyses. Each table contains specific data which is detailed below.

Note: NIP refers to the Nutrient Information Panel.

Table 1: LabelNutrients

DocID

Resource ID assigned by Foodworks.online

RefID

ID 1 as entered on the General tab

RefID2

ID 2 as entered on the General tab

SeqNo

Indicates the display order of each nutrient on the nutrition information panel (NIP)

NutrientName

Nutrient name as displayed on the NIP

PerServe

Nutrient value as displayed on the NIP per serve

Per100g

Nutrient value as displayed on the NIP per 100g (this column will be blank when Show per 100mL, not per 100g is selected)

Per100mL

Nutrient value as displayed on the NIP per 100mL (this column will be blank unless Show per 100mL, not per 100g is selected)

DailyIntakePercent

Percentage daily intake value as displayed on the NIP (data is only available for nutrients that have Show % Daily Intake column toggled on)

PerServeValue

Nutrient value as it appears in the analysis pane per serve

Per100gValue

Nutrient value as it appears in the analysis pane per 100g

Per100mLValue

Nutrient value as it appears in the analysis pane per 100mL

DailyIntakePercentValue

Percentage daily intake value (data is only available for nutrients that have Show % Daily Intake column toggled on)

Table 2: LabelSettings

DocID

Resource ID assigned by Foodworks.online

RefID

ID 1 as entered on the General tab

RefID2

ID 2 as entered on the General tab

DatePublished

Timestamp to indicate when labelling information was exported (e.g. dd/mm/yyyy hh:mm:ss AM/PM)

DocName

Resource name as entered on the General tab

LabelName

Label name as entered in the Labelling tab > General subtab > Alternate label name

Folder

List of the tags applied to the resource (e.g. tag 1, tag 2)

ServeSize

The serve size as entered on the Ingredients tab, with the unit of measurement

Serves

The number of serves as entered on the Ingredients tab

ServesPerPack

The number of serves per pack as entered in the Labelling tab > General subtab > Serves per pack

IsPer100mL

Indicates if the NIP displays per 100mL, not per 100g

IngredientsStatement

The full ingredients statement as it appears on the food label

StorageInstructions

The full storage instructions as entered in Labelling tab > General subtab> Storage Instructions

AdvisoryStatement

The full advisory statement as generated and displayed on the food label

ContainsAllergensStatement

The full allergen summary statement as generated and displayed on the food label

ContaminantsStatement

The full may contain allergen summary statement as generated and displayed on the food label

Notes

Notes as entered on the General tab > Notes field

Description

Description as entered on the Labelling tab > General subtab > Label description field

Footer

As entered on the Labelling tab > General subtab > Message field

PreparationInstructions

Preparation instructions as entered on the Labelling tab > General subtab > Preparation instructions field

CountryOfOrigin

Country of origin selected from the dropdown list in Labelling tab > CoOL subtab > Country dropdown (e.g. Australia)

CountryOfOriginStatementType

Statement types as selected on the Labelling tab > CoOL subtab. Appears in the CSV as 10, 11, 12 or 13 where: 10 = Made in; 11 = Grown in; 12 = Product of; 13 = Packed in

CountryOfOriginStatement

Country of Origin statement per the previous column selections including the selected country and statement type per the previous columns

ShelfLifeType

Shelf life prefix statement types as entered on the Labelling tab > Shelf life subtab. Appears in the CSV as 0, 1 or 2 where: 0 = No shelf life statement; 1 = Use By; 2 = Best Before

ShelfLifeWords

Indicates the shelf life statement prefix in words. This column will either be empty (when no shelf life is selected), Use By or Best Before

ShelfLifeDays

As entered on the Labelling tab > Shelf life subtab > Days field

SecondaryShelfLifeDays

As entered on the Labelling tab > Shelf life subtab > Secondary shelf life days field

NetWeight

As entered on the Labelling tab > General subtab > Net weight field

NetWeightStatement

Full net weight statement as it appears in the label (e.g. Net weight: 150g)

CoOLAustraliaPercent

CoOL percent as calculated

CoOLAustralianPercentForBarChart

CoOL percent as calculated to be used in the Bar Chart graphic

CoOLStandardMarks

Indicates which Standard Mark graphic you have selected. Appears in the CSV as 1, 2 or 3 where: 1 = Bar chart and Kangaroo Logo; 2 = Bar chart only; 3 = No standard mark

CoOLOrientation

Indicates the Standard Mark graphic orientation you have selected. Appears in the CSV as 0 or 1 where: 0 = landscape; 1 = portrait

IsCoOLWarning

Indicates if a warning has been calculated for CoOL for this product

CoOLWarningMessage

Displays the warning message in full if applicable (e.g. ‘CoOL statement is only compliant if all significant ingredients are from Australia’). Where IsCoOLWarning is FALSE this column will be empty

CoOLErrorMessage

Displays the error message in full if applicable (e.g. Product Of Angola statement however Australian content is >0%). Where IsCoOLError is FALSE this column will be empty

IsCoOLError

Indicates if an error has been calculated for CoOL for this product

CoOLStandardMarksImage

Name of the CoOL Standard Mark graphic used for this food based you selections for CoOL, see Download Country of Origin and Health Star Rating assets to download all graphics

HSRStars

Health Star Rating (HSR) value to 1 decimal place (e.g. 3.5)

HSRStyle

The HSR style selected. Appears in the CSV as 0, 1, 2 or 3 where: 0 = none; 1 = HSR only; 2 = HSR + energy; 3 = HSR + energy + 3 prescribed nutrients

HSRImage

Name of the HSR graphic used for this food based on the conditions set for HSR, see Download Country of Origin and Health Star Rating assets to download all graphics

HSRUnits

Unit of measurement for HSR. Appears in the CSV as 0, 1 or 2 where: 0 = Per 100g; 1 = Per 100mL; 2 = Per pack

HSRUnitsStatement

As selected in FwO in the Labelling tab > HSR subtab > HSR unit dropdown. This column will read either Per 100g, Per 100mL, Per Pack

HSREnergy

HSR energy value for use in the HSR graphic

HSRSaturatedFat

HSR saturated fat value for use in the HSR graphic

HSRSugars

HSR sugars value for use in the HSR graphic

HSRSodium

HSR sodium value for use in the HSR graphic

EnergySE_Per100g

Energy value as it appears in the Per 100g column on the NIP. If Show calories is enabled this the calorie value is also displayed [e.g. 418 kJ (100 Cal)]

Protein_Per100g

Protein value as it appears in the Per 100g column on the NIP

Totalfat_Per100g

Total fat value as it appears in the Per 100g column on the NIP

Saturatedfat_Per100g

Saturated fat value as it appears in the Per 100g column on the NIP

CarbohydrateSE_Per100g

Carbohydrate value as it appears in the Per 100g column on the NIP

Sugars_Per100g

Sugars value as it appears in the Per 100g column on the NIP

Sodium_Per100g

Sodium value as it appears in the Per 100g column on the NIP

EnergySE_PerServe

Energy value as it appears in the Per Serve column on the NIP. If Show calories is enabled this the calorie value is also displayed [e.g. 418 kJ (100 Cal)]

Protein_PerServe

Protein value as it appears in the Per Serve column on the NIP

Totalfat_PerServe

Total fat value as it appears in the Per Serve column on the NIP

Saturatedfat_PerServe

Saturated fat value as it appears in the Per Serve column on the NIP

CarbohydrateSE_PerServe

Carbohydrates value as it appears in the Per Serve column on the NIP

Sugars_PerServe

Sugars value as it appears in the Per Serve column on the NIP

Sodium_PerServe

Sodium value as it appears in the Per Serve column on the NIP

EnergySE_Per100mL

Energy value as it appears in the Per 100mL column on the NIP (where applicable). If Show calories is enabled this the calorie value is also displayed [e.g. 418 kJ (100 Cal)]

Protein_Per100mL

Protein value as it appears in the Per 100mL column on the NIP (where applicable)

Totalfat_Per100mL

Total fat value as it appears in the Per 100mL column on the NIP (where applicable)

Saturatedfat_Per100mL

Saturated fat value as it appears in the Per 100mL column on the NIP (where applicable)

CarbohydrateSE_Per100mL

Carbohydrates value as it appears in the Per 100mL column on the NIP (where applicable)

Sugars_Per100mL

Sugars value as it appears in the Per 100mL column on the NIP (where applicable)

Sodium_Per100mL

Sodium value as it appears in the Per 100mL column on the NIP (where applicable)
